Small Portion Cups Production
Without Waste
Suitable for packaging of butter, cheese, jam, honey, chocolate dessert, etc.

• Capacity: up35 cycle/min
• Dimension (m): 6(L) x 2.5(W) x 3.5(H)
• Electrical Supply: 3 PH, 380 VAC
• Air Pressure: 6 bar

 Changing of Production and expiry date at bottom of cups,needless for mold disassembling
 Knife Semi-cut at cups’ opening corner for easy opening
 UV radiation for film and foil
 Piston filling system with Servo Motor driving with minimum volume tolerance
 Filling CIP System needless fordisassembling of nozzles’ parts and pulling out of film
 Servo Motor-driven pulling system
 Cups’ one cycle-punching that results in cups’ smooth peripheral edge
 HEPA filter with UV radiation for supplying of cabin’sclean air pressure
 Capablefor considering cups’ cartoning system at the end of machine
 Capable for considering embossed decor at the cups’ wall
 Chassis and all filling parts are Stainless Steel
 All aluminum parts are hard anodized and all steel parts are hard chrome coated
 All electrical equipment includingPLC, Servo Motors, HMI and Motor Drives are Schneider
 Easy troubleshooting by monitoring of all alarms and errors at HMI
 PLC remote troubleshooting and upgrading via internet
